Ford Dashboard Symbols and Meanings for a High-Kilometre Truck in Brockville, Ontario
Ford dashboard symbols and meanings, in Ford Canada's own words: an orange or red warning light means your vehicle "should be promptly taken to a Ford Dealer", and four lamps in Ford's guide say to stop or warn against driving on.
Before the first cold snap, three more are worth knowing on a high-kilometre truck around Brockville, Ontario: tire pressure, stability control and the battery.
If a light just came on in your F-150 on the way to a job in Augusta, this is Ford's meaning in Ford's words, plus a straight answer on whether to keep driving or book it in.
The service team at Brockville Ford on Eleanor Street would rather read the code than guess at it.
Key Takeaways
Ford Canada says an orange or red warning light means the vehicle "should be promptly taken to a Ford Dealer", and "When the light is yellow, service may be required, and you should have a dealer inspect your vehicle."
Ford's guide says to stop for engine coolant temperature and engine oil, does not recommend driving with the Powertrain Fault light on, and says driving with the brake system warning lamp on "is dangerous."
Transport Canada says "Tire pressure goes down in the cold", and Ford says to check the tire pressure as soon as possible when the low tire pressure warning stays on.
Ford says the stability control light "flashes when the system is active." If it stays on, Ford calls that a system error, says "the system switches off", and says to have it checked by a Ford Dealer "immediately".
Not every Ford has every lamp, so your owner's manual is the final word for your model year. When a light stays with you, book a diagnosis online.
Reading Ford Dashboard Symbols and Meanings by Colour
Ford Canada's guide splits Ford dashboard symbols and meanings into two groups: warning lamps "alert you to a vehicle condition that may become serious", and indicator lights "show you when a feature is being used".
For warning lamps, Ford's rule is short: "If the warning light is orange or red, it means your vehicle is experiencing a problem and should be promptly taken to a Ford Dealer."
Ford adds: "When the light is yellow, service may be required, and you should have a dealer inspect your vehicle."
For indicator lights, Ford's note reads: "When a light on your dashboard is green or blue, it means that a vehicle feature is being used or has been activated."
You will see a tidy red, amber and green rule on plenty of websites. Ford Canada's page does not say red means stop, and it groups orange with red, not with yellow.
Colour is not the whole story either. Four lamps in Ford's guide say to stop or warn against driving on, and the next section covers them.
A light that comes on for a moment at start-up may simply be the truck checking itself. Ford says "Some lamps turn on when you start your vehicle to make sure they work."
Not every Ford has every lamp. If the one on your dash is not in Ford's guide, Ford says to "refer to your vehicle's Owner's Manual", where the Warning Lamps and Indicators section is the place to look.
The Ford Warning Lights That Say Stop or Warn Against Driving
Four warning lamps in Ford Canada's guide say to stop or warn against driving on: engine coolant temperature, engine oil, powertrain fault and the brake system warning lamp.
Ford says to stop for the first two, "We do not recommend you drive while this light is illuminated" for a powertrain fault, and that driving with the brake system warning lamp on "is dangerous."
Engine Coolant Temperature
Ford Canada's guide says: "It illuminates when your vehicle coolant temperature is high. Stop your vehicle as soon as possible, switch off your vehicle, and let it cool."
Ford names the lamp "Engine or Motor Coolant Temperature". On a loaded truck on Highway 401 or a gravel concession road, that wording leaves no room for driving it home first.
Once the engine is off and cool, the next question is why the lamp came on. Ford's guide says "To understand which vehicle code is causing a light to turn on, contact your Ford Dealer."
Engine Oil
Ford Canada's guide says: "If it illuminates with the engine running or when you are driving, this indicates a system error. Stop your vehicle as soon as it is safe to do so and switch the engine off."
Ford adds: "Check the engine oil level."
Ford's note on this lamp says: "Do not resume your journey if it illuminates despite the level being correct. Have the system checked by a Ford Dealer immediately."
Ford ties this lamp to a system error, not to when your next oil change is due. If the level reads correct and the lamp is still on, the truck stays put.
On either the coolant or the oil lamp, the job site can wait.
Powertrain Fault
Ford says this lamp "illuminates when the system detects a powertrain or a four-wheel drive (4WD)/all-wheel drive (AWD) fault." The four-wheel drive and all-wheel drive part applies to vehicles that have them.
Ford adds: "We do not recommend you drive while this light is illuminated. Contact a Ford Dealer as soon as possible."
Brake System Warning Lamp
Ford Canada's guide says: "If the lamp illuminates when you are moving, you may have the parking brake applied. Make sure the parking brake is off."
Ford adds: "Have your vehicle checked by a Ford Dealer as soon as possible if the lamp continues to illuminate."
Ford's guide also warns: "Driving your vehicle with the warning lamp on is dangerous. A significant decrease in braking performance may occur."
Ford also says: "It may take you longer to stop your vehicle."
On a loaded truck coming down a gravel grade, that is not a warning to test.
Ford calls this a dual-function lamp. It comes on when you apply the parking brake with the ignition on, and when "Your vehicle has a brake fault or low brake fluid level, regardless of the parking brake position."
Three Ford Warning Lights to Know Before the First Cold Snap
Before the first cold snap in Leeds and Grenville, three lights are the ones to understand on a truck that sits outside overnight: low tire pressure, stability control and the battery.
Transport Canada says "Tire pressure goes down in the cold", Ford says a flashing stability control light means the system is active, and Ford says a battery light while driving means switching off unnecessary electrical equipment and having the system checked.
The Low Tire Pressure Warning on a Cold Morning
Ford Canada's guide says of the low tire pressure warning: "It illuminates when the tire pressure is low. If the lamp remains on with the engine running or when driving, check the tire pressure as soon as possible."
Ford adds that the lamp comes on briefly when you switch the ignition on, and "If it does not illuminate when you switch the ignition on or begins to flash at any time, have the system checked by a Ford Dealer."
The cold is where Transport Canada comes in, not Ford. Transport Canada says "A tire that has good pressure when checked in a warm garage will be under-inflated when it's below zero outside."
It adds: "Tire pressure goes down in the cold, which is why you should do your checks when the tires are cold."
So tires that checked out fine in a heated shop can be under-inflated after a night below zero in an Augusta driveway.
What Ford says to do when the light comes on:
Check the pressure and inflate "to the Ford-recommended tire pressure", as Ford Canada's tire pressure monitoring page puts it.
Find that pressure on the "Tire Label inside the driver's door of your vehicle or your Owner's Manual".
Check with a gauge when the tires are cold, which is when Transport Canada says to do it.
Ford is clear that the light is not the whole job: "The tire pressure monitoring system is not a substitute for manually checking tire pressures."
It also watches only the tires on the road. Ford says the system looks for "significant under-inflation in any of the tires, excluding the spare."
If a winter tire swap is on the list anyway, our guide on when to put winter tires on in Ontario explains the timing and what the swap checks. The Winter Tire Package page is where to start on the tires themselves.
A Flashing Stability Control Light on a Slick Road
Ford Canada's guide says the stability control light "flashes when the system is active." Ford adds: "If it remains illuminated or does not illuminate when you switch the ignition on, this indicates a system error."
On wet leaves or the first slush on a back road near Lyn, that is the difference to watch for. By Ford's description, flashing means the system is active.
A light that stays on is different. Ford says that during a system error "the system switches off", and to have it checked by a Ford Dealer "immediately".
On a slick back road, a steady light means you are driving without stability control until it is fixed.
There is also a separate Stability Control Off lamp. Ford says it "illuminates when you switch the Stability Control System off" and "turns off when you switch the system back on or when you switch the ignition off."
The Battery Light While You Drive
Ford Canada's guide says: "If it illuminates while driving and indicates a system error, switch off all unnecessary electrical equipment and have the system checked by a Ford Dealer immediately."
On a work truck, that means the work lights and anything plugged into the truck go off, and the truck comes in.
For the rest of the electrical picture, our guide to Ford F-150 electrical problems on a high-kilometre truck explains where a technician starts, with the battery and charging system first.
Other Ford Warning Lights and What Ford Canada Says They Mean
The rest of the warning lamps in Ford Canada's guide describe a fault or a system error, and Ford's instruction ranges from "immediately" for ABS to "as soon as possible" for the front airbag.
Ford's page-level rule still applies: an orange or red warning light means the vehicle "should be promptly taken to a Ford Dealer".
Several apply only to vehicles with that system, so check your owner's manual for your model year.
Anti-Lock Braking System (ABS)
Ford Canada's guide says: "If it illuminates when you are driving and indicates a system error, you continue to have the normal braking (without ABS) unless the brake system warning lamp also illuminates. Have the system checked by a Ford Dealer immediately."
If the brake system warning lamp comes on with it, Ford's warning on that lamp applies.
Service Engine Soon
Ford Canada's entry says it "illuminates when you switch the ignition on prior to engine start to check the bulb and to indicate whether your vehicle is ready for Inspection and Maintenance (I/M) testing."
Ford says that normally it "automatically turns off if no system errors are present" once the engine starts.
Ford also says: "If after 15 seconds it flashes 8 times, this indicates that your vehicle is not ready for Inspection and Maintenance (I/M) testing."
That is Ford's Inspection and Maintenance readiness check, a different thing from a light that continuously flashes.
Ford's entry goes on: "If it illuminates when the engine is running this indicates the On-Board Diagnostics system has detected an error in the vehicle emission control system. Contact your Ford Dealer."
For a light that keeps flashing, Ford says: "If it continuously flashes, an engine misfire may be occurring. Continuing to drive your vehicle may cause reduced power or the engine to stop."
Ford also warns: "Failure to respond to the warning lamp may cause component damage not covered by the vehicle warranty."
Ford adds: "Have your vehicle checked as soon as possible. See your Ford Dealer to find out what the codes mean."
If the truck was recently serviced somewhere and the light is still on, Ford's guide says: "If your vehicle has been recently serviced and your engine light remains on, contact your Ford Dealer."
Front Airbag
Ford says: "If it does not illuminate when you switch the ignition on, continues to flash, or remains on when the engine is running, this indicates a malfunction. Have your vehicle checked by a Ford Dealer as soon as possible."
A safety system is the last one to leave for later.
Three More Warning Lamps in Ford's Guide
Ford Canada's guide also lists these three warning lamps:
Loose Gas Cap Warning. Ford says it "illuminates when there is a problem with the cap, including it being too loose, too tight, missing, dirty, or broken", that "you can check the cap yourself", and "if your gas cap is in place correctly, visit your Ford Dealer for diagnosis."
Low Beam Warning. Ford says it "illuminates when the low beam headlamp bulb is not functioning properly."
Electric Park Brake, on vehicles that have one. Ford says it "illuminates or flashes when the electric parking brake has a system error."
Ford Indicator Lights That Show a Feature Is in Use
Ford says indicator lights "show you when a feature is being used", and that a green or blue light means a vehicle feature "is being used or has been activated."
Two deserve a second look on a work truck: the Overdrive Off light, and the Message Indicator, which Ford says "may be red or amber depending on how serious the issue is."
The indicator lights in Ford Canada's guide:
Stability Control Off. On when the stability control system has been switched off, as covered above.
Trailer Tow Mode, on vehicles that have it. Ford says it "illuminates when Tow Mode is enabled on your vehicle."
Grade Assist and Overdrive Cancel, on vehicles that have it. Ford says it "illuminates when grade assist is turned on."
Overdrive Off, on vehicles that have it: "When the light is on, the transmission does not shift into overdrive." Ford adds: "If the light does not come on when the transmission control switch is depressed or if the light flashes when you are driving, visit a Ford Dealer."
Auto Hold, on vehicles that have it. Ford says "Auto Hold keeps the vehicle at a complete stop until you press the accelerator."
Normal Drive Mode, on vehicles that have it. Ford says it "illuminates when your vehicle is in the Normal drive mode."
Message Indicator. Ford says "It illuminates when your vehicle has a new message for you."
What to Do When a Ford Warning Light Comes On
Stop for the engine coolant temperature or engine oil lamp, as Ford says. Ford does not recommend driving with the Powertrain Fault light on, and says driving with the brake system warning lamp on "is dangerous."
For the battery, ABS and stability control lights, Ford says to have the system checked by a Ford Dealer "immediately", and for any other orange or red warning light, the vehicle "should be promptly taken to a Ford Dealer".
If the Service Engine Soon light continuously flashes, Ford warns that continuing to drive "may cause reduced power or the engine to stop" and says to have the vehicle checked as soon as possible.
Ford's guide is general. The Warning Lamps and Indicators section of your owner's manual is the final word for your model year.
On an out-of-warranty truck, the light is also the moment you decide where the diagnosis happens. Ask for the code, what it means and the estimate in writing before any work starts.
Our service department is a Ford dealer service lane, which is where Ford's guide sends you to find out what a code means.
Book a diagnosis online and tell the advisor which light came on, whether it flashed or stayed on, and what the truck was doing at the time.
If the diagnosis says the truck is nearer the end of its working life than you hoped, that is a conversation for another day, at your own pace. Start by valuing your trade or browsing our pre-owned inventory.
Frequently Asked Questions
What do the colours of Ford warning lights mean
Ford Canada says "If the warning light is orange or red, it means your vehicle is experiencing a problem and should be promptly taken to a Ford Dealer." It adds, "When the light is yellow, service may be required, and you should have a dealer inspect your vehicle."
For indicator lights, Ford says "When a light on your dashboard is green or blue, it means that a vehicle feature is being used or has been activated."
Which Ford dashboard lights mean stop driving
Ford Canada's guide says to stop for two lamps and warns against driving on with two more. For engine coolant temperature, Ford says "Stop your vehicle as soon as possible, switch off your vehicle, and let it cool."
For engine oil, Ford says "Stop your vehicle as soon as it is safe to do so and switch the engine off." For a powertrain fault, Ford says "We do not recommend you drive while this light is illuminated."
Of the brake system warning lamp, Ford says "Driving your vehicle with the warning lamp on is dangerous."
Ford's entry for a continuously flashing Service Engine Soon light warns that continuing to drive "may cause reduced power or the engine to stop", and says to have the vehicle checked as soon as possible.
What should I do if my Ford tire pressure light comes on in the cold
Ford says to "check the tire pressure as soon as possible" and inflate "to the Ford-recommended tire pressure", shown on the tire label inside the driver's door or in your owner's manual.
Transport Canada, not Ford, explains the cold: "Tire pressure goes down in the cold, which is why you should do your checks when the tires are cold."
What does a flashing stability control light mean on a Ford
Ford Canada says the stability control light "flashes when the system is active." Ford adds: "If it remains illuminated or does not illuminate when you switch the ignition on, this indicates a system error."
During a system error, Ford says "the system switches off", and to have it checked by a Ford Dealer "immediately".
Are the dashboard symbols the same on an F-150 and an Escape
Ford Canada's warning and indicator light guide names no model or model year, and several lamps apply only to vehicles with that system. For your own F-150 or Escape, Ford says to "refer to your vehicle's Owner's Manual", in its Warning Lamps and Indicators section.
Book a Ford Warning Light Check in Brockville, Ontario
The short version of Ford dashboard symbols and meanings: stop for engine coolant temperature or engine oil, don't drive on with a powertrain fault, and take Ford's warning that driving with the brake system warning lamp on is dangerous.
Take any other orange or red warning light to a Ford Dealer promptly, as Ford Canada's guide says. Before the first cold snap, check tire pressure with a gauge when the tires are cold.
A flashing stability control light means the system is active, and a steady one means a system error Ford says to have checked immediately.
Book your Ford warning light check online and ask for the code and the estimate in writing before any work starts.
